Nostop Reversible AC Synchronous Motor NSR-5038 Series

Features:

1.Shaftdiameteris:Ø7.0mm.Shaftlengthandshapecanbeanyasneeded.

2.Reversible.MotorrotationdirectioncanbeeitherinCWorinCCW.

3.Lowlifetime,lownoise,Stableperformance.

4.Ifcustomerneedshighertorque,wecanusetheNd-Fe-Bmagnet.

5.CE,UL,TUVapproved.

Main Applications:

MainlyusedforallkindsofAutomaticCurtains,StageLights,ElectricMachine,AutomaticElectricInstrumentsandmeters,etc.

Performances of the Motor after Gear Reduction (@ 50Hz) :

General Specifications:

1. Rated Voltage:  220-240(canbeanyvalueduringtherangeof12–240VAC)

2. Rated Frequency:   50Hz,60Hzor50/60Hzboth

3. Rated Input Power:   7.0Watts(Max.)

4. Rated Input Current:   70mA(Max.)for100-120VAC,or35mA(Max.)for220-240VAC

5. Noise Level:   45dB(A)Max

6. Temperature Rise (△T):   60KMax

7. Direction of Rotation:   CWorCCW(controlledbydifferentconnectionmethodofthecapacitor)

8. Speed v.s. Torque:   see as following chart

Speed	@50Hz	rpm	1.04	1.7	2.5	5	8	12.5	16.7	27.5	28.6	33	50	66.7	100	150
	@60Hz	ron	1.25	2	3	6	9.6	15	20	33	34	40	60	80	120	180
Torque	@50Hz	Kg.cm	30.6	30.6	25.5	12.2	8.8	5.61	4.29	5.61	2.5	2.2	1.43	1.07	0.7	0.47
		N.cm	300	300	250	120	86	55	42	55	24.5	20.81	14	10.5	6.9	4.6
	@60Hz	Kg.cm	30.6	30.6	21.4	10.2	7.3	4.69	3.57	4.59	2.09	1.77	1.19	0.89	0.58	0.39
		N.cm	300	300	210	100	72	46	35	45	20.5	17.3	11.7	8.7	5.7	3.8

Remarks:

Theabovetorquevaluesrefertotheminimumtorquevalues.
