| Type | Ratd voltage (VDC) | No-load speed (r/min) | No-load current (mA) | Rated speed (r/min) | Rated torque (mN.m) | Output power (W) | Rated current (mA) | Stall torque (mN.m) | Stall current (A) |
| 35ZY40-1230 | 12 | 3000 | 90 | 2300 | 9 | 2.1 | 400 | 38.5 | 0.8 |
| 35ZY40-1240 | 12 | 4000 | 100 | 3200 | 10 | 3.3 | 550 | 50 | 2.1 |
| 35ZY40-1250 | 12 | 5000 | 110 | 4300 | 8 | 3.5 | 600 | 57 | 2.2 |
| 35ZY40-2430 | 24 | 3000 | 50 | 2300 | 9 | 2.1 | 210 | 38.5 | 1.5 |
| 35ZY40-2440 | 24 | 4000 | 55 | 3000 | 10 | 3.1 | 230 | 40 | 0.7 |
| 35ZY40-2450 | 24 | 5000 | 60 | 4100 | 10 | 4.2 | 380 | 55.5 | 2.0 |
| Redution ratio | 3.7 | 5.2 | 14 | 19 | 27 | 51 | 71 | 100 | 139 | 189 | 264 | 369 |
| Number of gear trains | 1 | 1 | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 4 | 4 | 4 |
| Length(L) mm | 31.5 | 31.5 | 36.0 | 36.0 | 36.0 | 42.0 | 42.0 | 42.0 | 42.0 | 48.5 | 48.5 | 48.5 |
| No-load speed r/min | 808 | 579 | 214 | 157 | 111 | 59 | 42 | 30 | 21 | 16 | 11 | 8.1 |
| Rated speed r/min | 619 | 444 | 164 | 121 | 85 | 45 | 32 | 23 | 16 | 12 | 10 | 7.4 |
| Rated torque N.m | 0.031 | 0.044 | 0.11 | 0.15 | 0.21 | 0.39 | 0.54 | 0.77 | 1 | 1 | 1 | 1 |
| Max.permissible load in a short time N.m | 0.6 | 0.6 | 1.2 | 1.2 | 1.2 | 2.4 | 2.4 | 2.4 | 3 | 3 | 3 | 3 |
| Redution ratio | 3.7 | 5.2 | 14 | 19 | 27 | 51 | 71 | 100 | 139 | 189 | 264 | 369 |
| Number of gear trains | 1 | 1 | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 4 | 4 | 4 |
| Length(L) mm | 31.5 | 31.5 | 36.0 | 36.0 | 36.0 | 42.0 | 42.0 | 42.0 | 42.0 | 48.5 | 48.5 | 48.5 |
| No-load speed r/min | 1078 | 772 | 285 | 2100 | 148 | 78 | 56 | 40 | 29 | 21 | 15 | 11 |
| Rated speed r/min | 862 | 617 | 228 | 168 | 118 | 63 | 45 | 32 | 23 | 17 | 12 | 10 |
| Rated torque N.m | 0.035 | 0.049 | 0.12 | 0.17 | 0.24 | 0.43 | 0.6 | 0.85 | 1 | 1 | 1 | 1 |
| Max.permissible load in a short time N.m | 0.6 | 0.6 | 1.2 | 1.2 | 1.2 | 2.4 | 2.4 | 2.4 | 2.4 | 3 | 3 | 3 |
| Redution ratio | 3.7 | 5.2 | 14 | 19 | 27 | 51 | 71 | 100 | 139 | 189 | 264 | 369 |
| Number of gear trains | 1 | 1 | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 4 | 4 | 4 |
| Length(L) mm | 31.5 | 31.5 | 36.0 | 36.0 | 36.0 | 42.0 | 42.0 | 42.0 | 42.0 | 48.5 | 48.5 | 48.5 |
| No-load speed r/min | 1347 | 965 | 357 | 263 | 189 | 98 | 70 | 50 | 36 | 26 | 19 | 13 |
| Rated speed r/min | 1159 | 830 | 307 | 226 | 159 | 84 | 60 | 43 | 31 | 23 | 16 | 11 |
| Rated torque N.m | 0.028 | 0.039 | 0.10 | 0.13 | 0.19 | 0.33 | 0.46 | 0.65 | 0.9 | 1 | 1 | 1 |
| Max.permissible load in a short time N.m | 0.6 | 0.6 | 1.2 | 1.2 | 1.2 | 2.4 | 2.4 | 2.4 | 2.4 | 3 | 3 | 3 |
| Type | Ratd voltage (VDC) | No-load speed (r/min) | No-load current (mA) | Rated speed (r/min) | Rated torque (mN.m) | Output power (W) | Rated current (mA) | Stall torque (mN.m) | Stall current (A) |
| 35ZY40-1230 | 12 | 3000 | 90 | 2300 | 9 | 2.1 | 400 | 38.5 | 0.8 |
| 35ZY40-1240 | 12 | 4000 | 100 | 3200 | 10 | 3.3 | 550 | 50 | 2.1 |
| 35ZY40-1250 | 12 | 5000 | 110 | 4300 | 8 | 3.5 | 600 | 57 | 2.2 |
| 35ZY40-2430 | 24 | 3000 | 50 | 2300 | 9 | 2.1 | 210 | 38.5 | 1.5 |
| 35ZY40-2440 | 24 | 4000 | 55 | 3000 | 10 | 3.1 | 230 | 40 | 0.7 |
| 35ZY40-2450 | 24 | 5000 | 60 | 4100 | 10 | 4.2 | 380 | 55.5 | 2.0 |
| Redution ratio | 3.7 | 5.2 | 14 | 19 | 27 | 51 | 71 | 100 | 139 | 189 | 264 | 369 |
| Number of gear trains | 1 | 1 | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 4 | 4 | 4 |
| Length(L) mm | 31.5 | 31.5 | 36.0 | 36.0 | 36.0 | 42.0 | 42.0 | 42.0 | 42.0 | 48.5 | 48.5 | 48.5 |
| No-load speed r/min | 808 | 579 | 214 | 157 | 111 | 59 | 42 | 30 | 21 | 16 | 11 | 8.1 |
| Rated speed r/min | 619 | 444 | 164 | 121 | 85 | 45 | 32 | 23 | 16 | 12 | 10 | 7.4 |
| Rated torque N.m | 0.031 | 0.044 | 0.11 | 0.15 | 0.21 | 0.39 | 0.54 | 0.77 | 1 | 1 | 1 | 1 |
| Max.permissible load in a short time N.m | 0.6 | 0.6 | 1.2 | 1.2 | 1.2 | 2.4 | 2.4 | 2.4 | 3 | 3 | 3 | 3 |
| Redution ratio | 3.7 | 5.2 | 14 | 19 | 27 | 51 | 71 | 100 | 139 | 189 | 264 | 369 |
| Number of gear trains | 1 | 1 | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 4 | 4 | 4 |
| Length(L) mm | 31.5 | 31.5 | 36.0 | 36.0 | 36.0 | 42.0 | 42.0 | 42.0 | 42.0 | 48.5 | 48.5 | 48.5 |
| No-load speed r/min | 1078 | 772 | 285 | 2100 | 148 | 78 | 56 | 40 | 29 | 21 | 15 | 11 |
| Rated speed r/min | 862 | 617 | 228 | 168 | 118 | 63 | 45 | 32 | 23 | 17 | 12 | 10 |
| Rated torque N.m | 0.035 | 0.049 | 0.12 | 0.17 | 0.24 | 0.43 | 0.6 | 0.85 | 1 | 1 | 1 | 1 |
| Max.permissible load in a short time N.m | 0.6 | 0.6 | 1.2 | 1.2 | 1.2 | 2.4 | 2.4 | 2.4 | 2.4 | 3 | 3 | 3 |
| Redution ratio | 3.7 | 5.2 | 14 | 19 | 27 | 51 | 71 | 100 | 139 | 189 | 264 | 369 |
| Number of gear trains | 1 | 1 | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 4 | 4 | 4 |
| Length(L) mm | 31.5 | 31.5 | 36.0 | 36.0 | 36.0 | 42.0 | 42.0 | 42.0 | 42.0 | 48.5 | 48.5 | 48.5 |
| No-load speed r/min | 1347 | 965 | 357 | 263 | 189 | 98 | 70 | 50 | 36 | 26 | 19 | 13 |
| Rated speed r/min | 1159 | 830 | 307 | 226 | 159 | 84 | 60 | 43 | 31 | 23 | 16 | 11 |
| Rated torque N.m | 0.028 | 0.039 | 0.10 | 0.13 | 0.19 | 0.33 | 0.46 | 0.65 | 0.9 | 1 | 1 | 1 |
| Max.permissible load in a short time N.m | 0.6 | 0.6 | 1.2 | 1.2 | 1.2 | 2.4 | 2.4 | 2.4 | 2.4 | 3 | 3 | 3 |
