Brief Introduction :
Wheel: Aluminum Alloy Insulation System: Class E, B, F or H As Request
Housing: Galvanized Sheet or E-Coating Operating Temperature: -10°C To +50°C
Motor Type: Shaded Pole Motors NSP48 Series (can be others) Overheating Protection: T.P. or Z.P.
Bearing: Ball Bearing or Bronze Sleeve Electrical Connection: Lead Wire
Power Supply: 100 – 240VAC as Request RoHS Compliance: As Needed
Technical Performances (based on free air conditions) :
No. | Specifications | Power Supply | Input | Output | Max. Airflow | Max. Static Pressure | Noise | Dimensions | ||||
Volts | Freq’y | Power | Speed | Mertic | American | Metric | American | Level | A | B | ||
Model | (VAC) | (Hz) | (Watts) | (rpm) | (m 3 /h) | (CFM) | (Pa) | (in H 2 O) | [dB(A)] | (mm) | (mm) | |
①
| NAF30150-SP4815 | 230 | 50 | 10 | 2700 | 42 | 25.0 | 13.0 | 0.0523 | 35 | 160 | 35 |
120 | 60 | 8 | 3100 | 48 | 28.4 | 16.0 | 0.0643 | 40 | ||||
② | NAF30200-SP4815 | 230 | 50 | 11 | 2700 | 55 | 32.5 | 13.0 | 0.0523 | 35 | 498 | 35 |
120 | 60 | 8 | 3100 | 60 | 35.5 | 16.0 | 0.0643 | 41 | ||||
③ | NAF30250-SP4820 | 230 | 50 | 10 | 2600 | 67 | 40.0 | 12.0 | 0.0483 | 37 | 248 | 40 |
120 | 60 | 9 | 2900 | 73 | 43.0 | 14.5 | 0.0583 | 40 | ||||
④ | NAF30300-SP4820 | 230 | 50 | 13 | 2700 | 90 | 53.0 | 13.0 | 0.0523 | 38 | 303 | 40 |
120 | 60 | 12 | 3100 | 100 | 59.0 | 17.0 | 0.0684 | 42 | ||||
⑤ | NAF30350-SP4825 | 230 | 50 | 15 | 2600 | 100 | 59.0 | 12.0 | 0.0483 | 39 | 353 | 45 |
120 | 60 | 14 | 2900 | 110 | 65.0 | 15.0 | 0.0603 | 41 | ||||
Remarks: This catalog listed just some typical models. The performances as above are just for reference only. We can adjust our motor specifications according to what the customer needs. OEM & ODM are both welcome.
