Brief Introduction :
Wheel: Aluminum Alloy Insulation System: Class E, B, F or H As Request
Housing: Galvanized Sheet or E-Coating Operating Temperature: -10°C To +70°C
Motor Type: Brushless DC Motor Overheating Protection: T.P. or Z.P.
Bearing: Ball Bearing or Bronze Sleeve Electrical Connection: Lead Wire
Power Supply: DC 5V, 12V, 18V, 24V or As Request RoHS Compliance: As Needed
Technical Performances (based on free air conditions) :
No. | Specifications | Rated Volt. | Input Current | Output Speed | Max. Airflow | Max. Static Pressure | Noise | Dimensions | |||
Metric | American | Metric | American | Level | A | B | |||||
Model | (VDC) | (Amps) | (rmp) | (m 3 /h) | (CFM) | (Pa) | (in H 2 O) | [dB(A)] | (mm) | (mm) | |
①
| NDF30200-BL3725 | 5 | 0.043 | 3200 | 65 | 38.2 | 28 | 0.1126 | 38 | 198 | 42 |
② | NDF30250-BL3725 | 12 | 0.045 | 3000 | 85 | 50.0 | 30 | 0.1206 | 33 | 248 | 42 |
③ | NDF30300-BL3725 | 18 | 18 | 2800 | 100 | 58.8 | 33 | 0.1327 | 39 | 303 | 40 |
④ | NDF30350-BL3725 | 24 | 0.50 | 2500 | 125 | 73.5 | 33 | 0.1327 | 40 | 353 | 37 |
Remarks: This catalog listed just some typical models. The performances as above are just for reference only. We can adjust our motor specifications according to what the customer needs. OEM & ODM are both welcome.
